Electronic Jacquard Loom 448N Needle 5376 Hooks Rapier Jacquard Weaving Loom

Electronic Jacquard Loom 448N Needle 5376 Hooks Rapier Jacquard Weaving Loom

Product Details:

Place of Origin: China
Brand Name: Goodfore
Certification: ISO

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Packaging Details: plastic film
Delivery Time: 35 working days
Payment Terms: T/T, L/C
Supply Ability: 2000/set per month
Get Best Price Contact Now

Detail Information

Condition: New Quality: High-quality
Type: Electronic Jacquard Material: Steel And Plastic
Color: Green Model: WGT24A-5376
High Light:

rapier Jacquard Weaving Loom

,

5376 hooks rapier Jacquard

,

5376 hooks Jacquard Loom

Product Description

WGT24A-5376 high speed electronic jacquard loom weavingmachines 2688 hooks air jet room rapier loom


Brief Introduction:
The electronic jacquard loom have various sizes of jacquard head for option and easy to adjust. The jacquard needle loom spare parts of chain link can be easily changed to pattern through pattern pieces.



Electronic Jacquard Loom Machine have strong stability can be increased the production capacity, and also can used jacquard head of suitable various series.

Specification:

Applicable Industries: weaving machine
Video outgoing-inspection: Available
Machinery Test Report: Not Available
Warranty of core components: 1 YEAR
Core Components: Motor
Type: electronic jacquard
Application: jacquard loom
Production Capacity: high speed
Place of Origin: Jiangsu, China
Brand Name: GOODFORE
Weight: 1.5-2.5tons
Power(W): 650rpm
Warranty: 1 YEAR
After-sales Service Provided: Free spare parts
Key Selling Points: jacquard head
Machine type: Jacquard head
Related product: harness set
Color: Green
Speed: 30~45 weft/min
Reed width: 20inch
Air Source: 0.45-0.8Mpa
Dimension(L*W*H): 2500*2500*2800mm
Input pattern: USB or Internet
Certification:

CE ISO



MODEL JACQUARD TAPE REED HEALD PICK MAX. R.P.M WEFT
NEEDLE LINES WIDTH FRAME PEPEAT POWER DENSITY
EDJ 4/65 192N~448N 4 65mm 8 36 2.4KW 750-900 3.5~36.7cm
EDJ 6/45 192N~384N 6 45mm 8 36 2.4KW 750-900 3.5~36.7cm
EDJ 8/30 120N~160N 8 30mm 8 36 2KW 750-900 3.5~36.7cm
EDJ 6/55 192N~448N 6 55mm 8 36 2.4KW 750-900 3.5~36.7cm
EDJ 8/45 192N~448N 8 45mm 8 36 2.4KW 750-900 3.5~36.7cm





Shipping

Packing 1 set of loom per standard wooden case
Payment terms T/T, L/C.Western Union.
Delivery of time The delivery time is 20 days for one 20ft container.25 days for one 40ft container
Port Guangzhou port.


Electronic Jacquard Loom 448N Needle 5376 Hooks Rapier Jacquard Weaving Loom 0Electronic Jacquard Loom 448N Needle 5376 Hooks Rapier Jacquard Weaving Loom 1



Features

  • Newly design stand and side plate provide strong stability of the machine which increased the speed and the production capacity.

  • The cover of the machine is made by ABS material and front cover is added to meet the international CE standard.

  • Upper take off roller leans forward, increasing the pulling power.

  • The plate of yarn feeder has redesign to steel spring, it will be more smoothly for the yarn passes at high speed.

  • Various sizes of jacquard head for option, easy to adjust with the module and electric control separated and may equip with Head.


Advantages
1. The open warp is horizontal construction.The iron frame runs at proper speed without having too much noise enhancing the stability and reliability of the machine.
2. The integration solenoid valve setting is small in size and sensitive while working.
3. Being the most advanced micro electronic jacquard unit, its construction is simple and compact, and it is easy to maintain.
4. The tension of warp is controlled automatically with the help of advanced technology
5. The easy-dismounting construction of monofilament can lessen the workers’ labor intensity.
6. The unique CAD printmaking system for woven tape is easy-to-use and is featured by the externally self-locking.
7. The woven flower shape is showed on windows directly and clearly.
8. Equipped with a built-in program and data system, the control system can record and show all kinds of producing data.It can also show all kinds of producing data.It can also show the fault point and its reason, and copy the data on time when accident happens.



Application

1. Luggage Straps
Luggage belt, suitcase straps, travel straps

2. Backpack Straps
Shoulder straps, sternum straps, compression straps

3. Pet leash
Tracking leash, Training leash

4. Elastic Tape
Jacquard elastic, Buttonhole elastic, Fold over elastic, Lingerie elastic

5. Shoelace
Shoestrings,bootlaces
